The HP0180W 12V8A mobility scooter charger is a powerful and reliable solution for charging 12V lithium and lead-acid batteries. Designed for mobility scooters, this 12-volt, 8-amp mobility scooter charger provides efficient charging with built-in safety features, including overcurrent, overheating, and reverse polarity protection.
It supports a wide range of battery types and ensures smooth, consistent charging, whether at home or in a healthcare facility. Its compact yet durable construction makes it easy to transport and ideal for everyday use. The high output current reduces charging time, helping users maintain their mobility without long waits.
Whether replacing an original unit or upgrading to a faster charger, the HP0180W delivers the reliable performance needed to keep mobility scooters running efficiently and safely.
Specifications
HP0180WA (L1) 12V 8A Lead Acid / Li-ion Battery Charger
| Model No. |
HP0180WA (L1) 12V 8A |
| Input Voltage |
AC 100V ~ 240V, 50/60Hz |
| Output Voltage |
16.8V ± 0.2V |
| Output Current |
8.0A ± 0.2A |
| Efficiency |
≥ 80% |
| Short Circuit Protection |
Stops charging (Red LED flashes: Short battery error) |
| Over Current Protection |
Stops charging when output current > 1.3 × rated current |
| Over Voltage Protection |
Stops charging when output voltage > Vmax × 1.05 |
| Feedback Protection |
Stops charging |
| Low Voltage Protection |
Stops charging |
| Timer Protection |
Stops charging |
| Operating Temperature |
0℃ ~ 40℃ |
| Operating Humidity |
20% ~ 85% |
| Storage Temperature |
-20℃ ~ 70℃ |
| Operating Height |
≤ 2000m |
| Dimensions |
185 × 93 × 55 mm |
| Weight |
0.81 kg |
| Case Material |
Black Plastic |
| LED Indication |
Power On: Red
Charging: Yellow
Charged: Green
Error (Short battery): Red LED flashes |
| Series Available |
HP0180WA(L1) – 12V Imax: 8A
HP0180WB(L2) – 24V Imax: 6A
HP0180WC(L3) – 36V Imax: 4A
HP0180WD(L4) – 48V Imax: 3A |
| RoHS Compliant |
Yes |
| Certifications |
TUV-GS, UKCA,cTUVus,CE,KC,SAA,FCC,PSE |
