The HP0180W 48V3A electric bike charger is a versatile charging solution designed for e-bikes using lithium or lead acid batteries. It delivers a stable 48V 3A output, enabling fast, efficient, and safe charging. Whether you’re charging at home or on the go, this electric bike charger 48V3A ensures your battery stays in optimal condition.
Built with smart protection features like short-circuit, overcurrent, and overvoltage protection, the HP0180W enhances battery life while minimizing safety risks. Its universal DC output design makes it compatible with a wide range of electric bikes. If you’re looking for a dependable electric bike charger, the HP0180W is an excellent choice for long-term, worry-free performance.
Specifications
HP0180WD(L4) 48V 3A Li-ion Battery Charger
| Model No. |
HP0180WD(L4)(13S) – 48V 3A |
| Input Voltage |
AC 100V ~ 240V, 50/60Hz |
| Output Voltage |
54.6V ± 0.2V |
| Output Current |
3.0A ± 0.1A |
| Efficiency |
≥ 80% |
| Short Circuit Protection |
Stops charging |
| Over Current Protection |
Stops charging when output current > 1.3 × rated current |
| Over Voltage Protection |
Stops charging when output voltage > Vmax × 1.05 |
| Feed Back Protection |
Stops charging |
| Low Voltage Protection |
Stops charging |
| Timer Protection |
Stops charging |
| Operating Temperature |
0℃ ~ 40℃ |
| Operating Humidity |
20% ~ 85% |
| Storage Temperature |
-20℃ ~ 70℃ |
| Operating Height |
≤ 2000m |
| Dimensions |
185 × 93 × 55 mm |
| Weight |
0.81 kg |
| Case Material |
Black Plastic with Fan |
| LED Indication |
Power On: Red
Charging: Yellow
Charged: Green
Error (Short battery): Red LED flashes |
| Series Available |
HP0180WA(L1) – 12V Imax: 8A
HP0180WB(L2) – 24V Imax: 6A
HP0180WC(L3) – 36V Imax: 4A
HP0180WD(L4) – 48V Imax: 3A |
| RoHS Compliant |
Yes |
| Certifications |
TUV-GS, UKCA, cTUVus, CE, KC, SAA, FCC |
